N9030A PXA Signal Analyzer

The highest-performance signal analyzer with multi-measurement application such as TV & Broadcasting (DVB-T/H/T2), Mobile Wireless Communication (2G/3G/4G), WLAN Measurement (802.11 a/b/g/n/ac)
The PXA Signal analyzer provides frequency coverage up to 50 GHz and ensures present and future flexibility through optional measurement capabilities and hardware expandability. The PXA’s advanced performance, flexibility, capability and expandability enable you to address demanding applications in aerospace, defense, commercial communications and more. In addition, the PXA includes extensive remote language compatibility features that make it easier to replace existing Agilent or HP performance spectrum analyzers.

::Key Features::

Functionality
[•] 3 Hz to 3.6, 8.4, 13.6, 26.5, 43, 44, or 50 GHz; internal preamplifier options up to 50 GHz.
[•] 10 MHz (standard), 25, 40, or 140 MHz analysis bandwidth (160 MHz will be available in February 2012)
[•] Extend frequency to 325 GHz and beyond with external mixing

Performance
[•] ±0.19 dB absolute amplitude accuracy
[•] +22 dBm third order intercept (TOI)
[•] -172 dBm displayed average noise level (DANL) with preamplifier and noise floor extension
[•] -83 dB (-88 dB nominal) W-CDMA ACLR dynamic range (with noise correction on)
Measurement Applications & Software
[•] PXA supports over 25 measurement applications, covering cellular communication, wireless connectivity, digital video, and general purpose. View full list of measurement applications
[•] Advanced analysis of more than 70 signal formats; software runs inside the PXA. 89600 VSA software
[•] MATLAB data analysis software for general purpose data analysis, visualization, and measurement automation. MATLAB software for X-Series
[•]Agilent's PowerSuite one-button power measurements included as standard

Automation & Communication Interface
[•] LXI class C compliant, SCPI and IVI-COM
[•] USB 2.0, 1000Base-T LAN, GPIB
[•] Programming remote language compatibility with PSA, 8566/68, 856x, and more
[•] Common X-Series user interface/Open Windows® XP operating system
